Blender光流踩坑记录

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140

# warp 部分代码摘自 ARFlow(https://github.com/lliuz/ARFlow)
import torch
import torch.nn as nn
import inspect
import numpy as np
import cv2
import Imath
import array
import OpenEXR
import matplotlib.pyplot as plt


def mesh_grid(B, H, W):
    # mesh grid
    x_base = torch.arange(0, W).repeat(B, H, 1)  # BHW
    y_base = torch.arange(0, H).repeat(B, W, 1).transpose(1, 2)  # BHW

    base_grid = torch.stack([x_base, y_base], 1)  # B2HW
    return base_grid


def norm_grid(v_grid):
    _, _, H, W = v_grid.size()

    # scale grid to [-1,1]
    v_grid_norm = torch.zeros_like(v_grid)
    v_grid_norm[:, 0, :, :] = 2.0 * v_grid[:, 0, :, :] / (W - 1) - 1.0
    v_grid_norm[:, 1, :, :] = 2.0 * v_grid[:, 1, :, :] / (H - 1) - 1.0
    return v_grid_norm.permute(0, 2, 3, 1)  # BHW2


    """
    :param data: unnormalized coordinates Bx2xHxW
    :return: Bx1xHxW
    """
    B, _, H, W = data.size()

    # x = data[:, 0, :, :].view(B, -1).clamp(0, W - 1)  # BxN (N=H*W)
    # y = data[:, 1, :, :].view(B, -1).clamp(0, H - 1)

    x = data[:, 0, :, :].view(B, -1)  # BxN (N=H*W)
    y = data[:, 1, :, :].view(B, -1)

    # invalid = (x < 0) | (x > W - 1) | (y < 0) | (y > H - 1)   # BxN
    # invalid = invalid.repeat([1, 4])

    x1 = torch.floor(x)
    x_floor = x1.clamp(0, W - 1)
    y1 = torch.floor(y)
    y_floor = y1.clamp(0, H - 1)
    x0 = x1 + 1
    x_ceil = x0.clamp(0, W - 1)
    y0 = y1 + 1
    y_ceil = y0.clamp(0, H - 1)

    x_ceil_out = x0 != x_ceil
    y_ceil_out = y0 != y_ceil
    x_floor_out = x1 != x_floor
    y_floor_out = y1 != y_floor
    invalid = torch.cat([x_ceil_out | y_ceil_out,
                         x_ceil_out | y_floor_out,
                         x_floor_out | y_ceil_out,
                         x_floor_out | y_floor_out], dim=1)

    # encode coordinates, since the scatter function can only index along one axis
    corresponding_map = torch.zeros(B, H * W).type_as(data)
    indices = torch.cat([x_ceil + y_ceil * W,
                         x_ceil + y_floor * W,
                         x_floor + y_ceil * W,
                         x_floor + y_floor * W], 1).long()  # BxN   (N=4*H*W)
    values = torch.cat([(1 - torch.abs(x - x_ceil)) * (1 - torch.abs(y - y_ceil)),
                        (1 - torch.abs(x - x_ceil)) * (1 - torch.abs(y - y_floor)),
                        (1 - torch.abs(x - x_floor)) * (1 - torch.abs(y - y_ceil)),
                        (1 - torch.abs(x - x_floor)) * (1 - torch.abs(y - y_floor))],
                       1)
    # values = torch.ones_like(values)

    values[invalid] = 0

    corresponding_map.scatter_add_(1, indices, values)
    # decode coordinates
    corresponding_map = corresponding_map.view(B, H, W)

    return corresponding_map.unsqueeze(1)


def flow_warp(x, flow12, pad='border', mode='bilinear'):
    B, _, H, W = x.size()

    base_grid = mesh_grid(B, H, W).type_as(x)  # B2HW

    v_grid = norm_grid(base_grid + flow12)  # BHW2
    if 'align_corners' in inspect.getfullargspec(torch.nn.functional.grid_sample).args:
        im1_recons = nn.functional.grid_sample(x, v_grid, mode=mode, padding_mode=pad, align_corners=True)
    else:
        im1_recons = nn.functional.grid_sample(x, v_grid, mode=mode, padding_mode=pad)
    return im1_recons


def warp_vis(cur, nxt, flow, pad='border', mode='bilinear'):
	"""
	cur, nxt, flow: ndarray, H * W * C
	"""

	device = 'cuda' if torch.cuda.is_available() else 'cpu'
	cur = torch.from_numpy(cur).double()[None].permute(0, 3, 1, 2).to(device)
	nxt = torch.from_numpy(nxt).double()[None].permute(0, 3, 1, 2).to(device)
	flow = torch.from_numpy(flow).double()[None].permute(0, 3, 1, 2).to(device)
	nxt_warp = flow_warp(nxt, flow, pad, mode)
	nxt_warp = nxt_warp[0].permute(1, 2, 0).cpu().numpy().astype(np.uint8)
	cur = cur[0].permute(1, 2, 0).cpu().numpy().astype(np.uint8)
	nxt = nxt[0].permute(1, 2, 0).cpu().numpy().astype(np.uint8)
	fig, axs = plt.subplots(1, 3)
	axs[0].imshow(cur)
	axs[0].set_title('cur')
	axs[1].imshow(nxt)
	axs[1].set_title('nxt')
	axs[2].imshow(nxt_warp)
	axs[2].set_title('nxt_warp')
	plt.show()


def exr2flow(exr_path, w, h):
	file = OpenEXR.InputFile(exr_path)
	FLOAT = Imath.PixelType(Imath.PixelType.FLOAT)
	(R,G,B,A) = [array.array('f', file.channel(Chan, FLOAT)).tolist() for Chan in ("R", "G", "B","A") ]
	flow = np.zeros((h,w,4), np.float64)
	flow[:,:,0] = np.array(R).reshape(flow.shape[0],-1)
	flow[:,:,1] = -np.array(G).reshape(flow.shape[0],-1)
	flow[:,:,2] = np.array(B).reshape(flow.shape[0],-1)
	flow[:,:,3] = -np.array(A).reshape(flow.shape[0],-1)
	return flow


if __name__ == '__main__':
    im1, im2, im3 = cv2.imread('0001.png'), cv2.imread('0002.png'), cv2.imread('0003.png')
    h, w = im1.shape[:2]
    flow = exr2flow('Flow0002.exr', w, h)
    warp_vis(im2, im1, flow[:,:,:2]) # R,G
    warp_vis(im2, im3, -flow[:,:,2:]) # B,A
